Netapp NS0-593 Dumps

= AutoSupport is enabled by default for Cloud Manager and ONTAP Cloud systems. It proactively monitors the health of your systems and sends messages to NetApp technical support. To enable AutoSupport, you must provide your NetApp Support site credentials to Cloud Manager. If your credentials are incorrect or expired, Cloud Manager will not be able to send AutoSupport messages to NetApp. Therefore, the solution for this issue is to verify that your NetApp Support site credentials are correctly added to Cloud Manager. References = Troubleshooting Cloud Manager and ONTAP Cloud, Set up AutoSupport

 Updating the Vscan servers one at a time can prevent the clients from losing access to the files on the CIFS SVM, as there will always be at least one Vscan server available for scanning. Disabling the -scan-mandatory flag in the Vscan policy can also avoid the issue, as it allows the clients to access the files even if there are no Vscan servers online, but this may compromise the security of the data. Enabling the -scan-mandatory flag or modifying the CIFS shares to be CA shares will not help, as they do not affect the availability of the Vscan servers or the scanning process. References = Vscan server installation and configuration, Update the Vscan On-Access policy configuration for an SVM

A B2B type consistency point (CP) occurs when a new CP is triggered before the previous CP is completed, due to the second memory buffer reaching a watermark. This can cause write latency to increase as user write operations are not replied until a write buffer frees up. However, this only affects the aggregate that is undergoing the B2B processing, and not the other aggregates on the same node. Therefore, the performance of the client operations on the data aggregates will not be affected by B2B processing on the root aggregate. References = What is the Back-to-Back (B2B) Consistency Point Scenario?, What are the different Consistency Point types and how are they measured in ONTAP 9?, What are the different Consistency Point types and how are they measured?

• The question refers to a scenario where the shelf firmware for an NS224 shelf has not been upgraded on one of the NVMe shelf modules (NSM) after a week of installation.
• The NSM is responsible for managing the communication between the drives and the I/O modules (IOM) in the shelf1.
• The shelf firmware for the NSM is automatically updated when the NSM is inserted into the shelf or when the system is rebooted2.
• If the automatic update does not work, the manual update process involves reseating the NSM, which means removing it from the shelf and inserting it back3.
• Reseating the NSM triggers the firmware update and also resets the NSM’s state3.
• The other options are not correct, because:
• NS224 NVMe drive shelf overview - NetApp
• Shelf firmware update process - NetApp
• Module firmware upgrade stuck on NS224 shelf - NetApp Knowledge Base
• Power cycle a disk shelf - NetApp

 To assign storage access to an NVMe protocol host, you need to configure the following objects:

• The NVMe subsystem, which is a logical entity that represents a group of NVMe namespaces that can be accessed by one or more hosts1.
• An NVMe LIF, which is a logical interface that provides network connectivity for the NVMe subsystem2.
• The NVMe namespace, which is a logical volume that is exposed to the host as an NVMe device1.

You do not need to configure the NVMe broadcast domain or the NVMe LUN, as these are not relevant for NVMe protocol host access. References = 1: Configuring NVMe-oF - Hitachi Vantara Knowledge 2: Basic VMware NVMe Architecture and Components

The error message indicates that the specified path “/vol1” does not exist in the namespace belonging to Vserver “svm1”. This means that the volume “vol1” has not been mounted to the Vserver’s namespace, which is required for creating a share. The volume type, the CIFS service status, and the CIFS service mode are not relevant to the error. References =

The error message indicates that the access is denied for user ‘anonymous user’ (Vserver 50), from client IP 10.10.10.10 accessing resource ‘/offload-target’. This means that the application is not providing a valid user name or access key to authenticate with the ONTAP S3 server. According to the NetApp documentation1, ONTAP S3 server supports both v2 and v4 signatures, but v2 signatures are deprecated and not recommended. Therefore, the application should use v4 signatures to access the ONTAP S3 bucket. Additionally, the application should specify the bucket name in the host name, not in the resource path, as shown in the following example2:

References = 1 ONTAP S3 Server Overview - NetApp Documentation 2 Accessing an ONTAP S3 bucket - NetApp Documentation

= The -transport parameter specifies the protocol used to send AutoSupport messages, which should be HTTPS by default. The -proxy-url parameter specifies the proxy server used to sendAutoSupport messages, which should be the Connector’s IP address and port if the Cloud Volumes ONTAP nodes do not have outbound internet access. These two parameters can be used to check the AutoSupport configuration and connectivity status. References = Verify AutoSupport setup, Troubleshoot your AutoSupport configuration, High-availability pairs in Azure

 = The Connector is a software component that enables Cloud Manager to manage resources and processes within your AWS environment. To deploy a Connector in AWS, you need to have the correct IAM policies attached to your user account or role. These policies grant the Connector the permissions to perform various actions on your behalf, such as creating and deleting EC2 instances, VPCs, security groups, and so on. If you do not have the required IAM policies, the deployment will fail with the message ‘Insufficient permissions to deploy Cloud Connector’. You can find the list of required IAM policies in the Connector deployment policy for AWS. References = Creating a Connector in AWS from Cloud Manager, page 3-4.

 FlexGroup requires CIFS shares to use the Continuously Available Feature, which enables transparent failover and recovery of SMB sessions in the event of a node failure or takeover. This feature is only supported by Windows 8 and later clients, and some printers and scanners may not support it either. Therefore, these older Windows XP clients and some printers and scanners are unable to access a FlexGroup over CIFS. References = Supported and unsupported configurations for FlexGroup volumes, NetApp ONTAP FlexGroup volumes — Best practices and implementation guide (page 24)

• The error message indicates that the ONTAP Select Deploy VM cannot connect to the vCenter server due to a network issue1.
• One possible cause of this issue is that the IP address of the ONTAP Select Deploy VM is conflicting with another device on the same network2.
• To correct this problem, you need to change the IP address of the ONTAP Select Deploy VM to a unique and valid address that can reach the vCenter server2.
• You can change the IP address of the ONTAP Select Deploy VM by using the Deploy web interface or the Deploy CLI2.
• After changing the IP address, you need to restart the Deploy services and re-add the vCenter server to the inventory2. References:
• 1: Credential authentication failed with: HostConnectionFailed, NetApp Knowledge Base
• 2: Changing the IP address of the Deploy VM, ONTAP Select 9 Documentation Center

= The NetApp sanlun command is a tool that returns information about the LUNs mapped to your host, multipathing, and information necessary to create initiator groups. It is part of the Linux Unified Host Utilities package, which also includes other tools to manage NetApp storage, such as failover policies and physical paths. To run the sanlun command, you must install the Host Utilities package on your Linux host. The other options are not relevant for this scenario, as they are either not required or not compatible with the Linux host. References = Install Linux Unified Host Utilities 7.1, SAN Toolkit

• A Twinax cable is a type of copper cable that is used to connect cluster ports to cluster switches1.
• A cluster port is a network port that is configured for cluster communication and data access2.
• A cluster switch is a network switch that is used to interconnect the nodes in a cluster and provide redundancy and load balancing3.
• A cluster network is a network that enables cluster communication and data access between the nodes in a cluster and external clients4.
• A cluster network can be degraded due to various reasons, such as misconfiguration, malfunction, or excessive link errors on the cluster ports or the cluster switches.
• Link errors are errors that occur on the physical layer of the network, such as CRC errors, length errors, alignment errors, or dropped packets.
• Link errors can indicate a problem with the cable, the switch port, the network interface card (NIC), or the cable connector.
• In this scenario, the alert messages state that the cluster network has degraded and the errors are being generated from Node 2, interface e0b.
• The first step to solve this problem is to replace the Twinax cable between Node 2, interface e0b and the NetApp CN1610 switch, as this could be the source of the link errors.
• Replacing the cable could resolve the issue and restore the cluster network to a healthy state.
• If replacing the cable does not solve the problem, then other steps may be required, such as checking the switch port, the NIC, or the cable connector, or replacing the switch or the motherboard. References:
• 1: Cluster network cabling, ONTAP 9 Documentation Center
• 2: Cluster ports, ONTAP 9 Documentation Center
• 3: Cluster switches, ONTAP 9 Documentation Center
• 4: Cluster network, ONTAP 9 Documentation Center
• [5]: How to troubleshoot CLUSTER NETWORK DEGRADED error messages, NetApp Knowledge Base
• [6]: Cluster network degraded due to high CRC errors on cluster ports, NetApp Knowledge Base

 According to the NetApp Knowledge Base, packet traces are stored in the /etc/log/packet_traces directory of the node hosting the LIF. This applies to ONTAP 9.10 and above systems. For ONTAP 9.2 to 9.9 systems, the procedure to capture packet traces is similar, but the command syntax is slightly different. For ONTAP pre-9.2 systems, the procedure is different and requires the use of the tcpdump command. References = How to capture packet traces on ONTAP 9.10+ systems, How to capture packet traces (tcpdump) on ONTAP 9.2 to 9.9 systems, How to capture packet traces in ONTAP pre-9.2

• IQN stands for iSCSI Qualified Name, which is a unique identifier for an iSCSI initiator or target1.
• ONTAP uses IQN to authenticate and authorize iSCSI sessions2.
• If two hosts have the same IQN, they will cause a conflict and ONTAP will reject the new session request from the second host3.
• This will result in the host losing the connection to the iSCSI target and then reporting that the session was reestablished, as shown in the exhibit.
• To avoid this problem, each host should have a unique IQN. References:
• iSCSI Qualified Name (IQN) - NetApp
• iSCSI authentication and authorization - NetApp
• Troubleshooting iSCSI issues - NetApp
• [Configuring iSCSI initiators - NetApp]

The VMware feature that is supported by ONTAP software to identify and follow I/Os from each VM on the shared FC LUN-backed datastores is Virtual machine ID (VMID). VMID is a unique identifier assigned to each VM by the vCenter Server. ONTAP software can use VMID to map the VMs to the FC LUNs and provide visibility into the I/O performance and latency of each VM. This feature is also known as Virtual Storage Console (VSC) for VMware vSphere12. References: 1:Virtual Storage Console for VMware vSphere | NetApp Documentation 2: How to use Virtual Storage Console (VSC) to monitor the performance of virtual machines - NetApp Knowledge Base

= A user quota is a limit on the amount of disk space or the number of files that a user can consume on a volume. A user can be represented by multiple IDs, such as UNIX user ID (UID), Windows user ID (SID), or name mapping ID. A file owned by any of these IDs is subject to the restriction of the user quota. If a user has files in different directories or qtrees within the same volume, all of those files count towards the user’s quota limit. Therefore, if other files within the volume are also owned by the user, they could exceed the user quota and prevent the user from saving more files to their home drive, even if the home drive itself shows minimal data usage. References = How quotas work with users and groups overview, ONTAP - How quotas work with users and groups

To access a LUN on a FAS 8300 system from a VMware ESXi server through the FC protocol, the customer must configure the FC service on the SVM that owns the LUN. The FC service enables the SVM to act as an FC target and communicate with the FC initiators on the host. Without the FC service, the LUN will not be visible to the host, even if the LUN is mapped to an igroup and the FC LIFs are up. The exhibit shows that the FC service is not configured on the SVM, as theoutput of the command vserver fcp initiator show -vserver SVM1 is empty. Therefore, the reason for the problem is that the FC service has not been configured on the SVM. References = Configure an SVM for FC, Create an FC protocol service, Single IQN iSCSI session with ESXi on ONTAP when igroup has two IQNs
