Tableau Desktop-Specialist Dumps

Explanation

In a box and whisker plot:

1) The ends of the box are the upper and lower quartiles, so the box spans the interquartile range

2) The median is marked by a vertical line inside the box

3) The whiskers are the two lines outside the box that extend to the highest and lowest observations.

Of course! As an example, see below:

1) Using the Sample Superstore data, let's plot a bar chart showing the Sales for each Category:

Observe that we have 3 marks - Each bar in a bar chart is called a mark. Similarly, each point in a scatter plot is also a mark , and so on for all charts.

1 row by 3 columns means that clearly on the y-axis (Sales), we have only a single mark - a single continous axis, but 3 different marks (Technology, Furniture and Office supplies ) on the x-axis.

2) Now let's add subcategory to the view as well (another dimension):

Observe that the number of marks has increased - i.e the number of Bars.

Also, notice we now have 1 row and 17 columns. Simply because 1 row = Sales (on the y-axis), and on the x-axis, we have 17 different columns (i.e product sub categories!!)

Very important question for the exam and appears quite a lot too.

The correct answer is - By dragging another dimension to Color on the Marks card.

Chart, bar chart Description automatically generated

This is what the question says we have already created. Now to convert this into a Stacked bar chart, we will drop another dimension on Color in the Marks card.

Chart, bar chart Description automatically generated

The rest won't create stacked bar charts, and hence are incorrect choices. The best way to answer such questions on the real exam is to quickly do what the options say and see if they satisfy the requirements in the question.

Explanation

As the names suggest, if we subtract the order date from the shipping date, we simply get the number of days between these 2 dates.

We can these use this calculated field in our charts, and can use COUNT, SUM, AVG etc with them according to our need.

From the official Tableau documentation:

As we can see below, Bar charts can be used as a floating object.

Explanation

Measures contain numeric quantitative values hence that option is incorrect.

Reference 1:

Reference 2:

*Very important question*

If we select the labels in the view and then group, a new consolidated mark is created - in our case bar since we are talking about a bar chart in the question. See below:

Then on grouping, a new bar is created, and the colour of all bars remain the same.

Had we grouped by choosing the marks instead of the labels, the following would be the result:

You should change the mark type of the view to configure the visualization as a density map. A density map is a type of mark that shows how data points are distributed in a two-dimensional space. To change the mark type, you can use the Marks card or Show Me. Changing the mark shape, creating a custom color palette, or selecting heat maps from Show Me will not create a density map2

Explanation

We can drag fields from the Data pane to create the structure for your visualizations.

The Columns shelf creates the columns of a table, while the Rows shelf creates the rows of a table. You can place any number of fields on these shelves.

These FIELDS are also referred to as PILLS. See below:

Explanation

There are two types of sets: dynamic sets and fixed sets. The members of a dynamic set change when the underlying data changes. Dynamic sets can only be based on a single dimension.

To create a dynamic set:

1) In the Data pane, right-click a dimension and select Create > Set.

2) In the Create Set dialog box, configure your set. You can configure your set using the following tabs:

General: Use the General tab to select one or more values that will be considered when computing the set.

You can alternatively select the Use all option to always consider all members even when new members are added or removed.

None of the other options exist, and therefore are incorrect answers.

When you click Salt Lake City in the view, the URL action will direct you to A URL action is a hyperlink that points to a web page or other web-based resource outside of Tableau. You can use URL actions to create an email or link to additional information about your data.  To customize links based on your data, you can automatically enter field values as parameters in URLs3 In this case, the URL action uses as the URL target, where is a field value from the view. When you click Salt Lake City in the view, Tableau will replace with Salt Lake City in the URL target. However, since spaces are not allowed in URLs, Tableau will encode them as + signs instead. Therefore, the final URL will be 3 The other options are not correct because they do not reflect how Tableau encodes field values in URL actions.

When exporting a view as an image in Tableau, the default export includes everything that is currently displayed in the view, with Tableau applying its own styling, including fonts. The default format for an exported image is PNG, which is a raster-based file format that captures all visual elements as pixels. PNG is widely used for its lossless compression and is suitable for detailed images like those produced by Tableau. Unlike vector-based images, PNGs do not embed fonts, and the image quality remains consistent when the image is viewed on different platforms, which makes it ideal for inserting into documents like Microsoft Word.

You should use a union when you have two tables with similarly named columns of data that you want to combine. A union is a method for combining data by appending rows of one table onto another table. The tables that you union must have the same number of fields, the same field names, and the same data types2

Explanation

You can union your data to combine two or more tables by appending values (rows) from one table to another. To union your data in Tableau data source, the tables must come from the same connection.

For example, suppose you have the following customer purchase information stored in three tables, separated by month. The table names are "May2016," "June2016," and "July2016."

A union of these tables creates the following single table that contains all rows from all tables.

Names and Categories would be mostly used as dimensions (categorical data).

Profit and measures contain quantitative data and would be more suitable for Measures!

Using the Sample superstore as a reference, click on the manage metadata icon as follows:

We can rename a particular column name to make it easier to remember and use in Tableau. Let's change Order ID to oID as shown:

Now, we'll see oID when using this data source in Tableau. This WILL NOT affect the original data source. The remote field name let's us see what the name of the column is in the ORIGINAL Data source.

Explanation

By default, measures placed in a view are aggregated by SUM, which means that the data for that field in all of the rows is combined. Measures can also be aggregated as average, median, count, or count distinct.

Explanation

SUM is an aggregate function, not a table calculation!

A table calculation is a transformation you apply to the values in a visualization. Table calculations are a special type of calculated field that computes on the local data in Tableau. They are calculated based on what is currently in the visualization and do not consider any measures or dimensions that are filtered out of the visualization.

The most common Table calculations are:

Running Total

Percent Difference

Difference

Percent of Total

Rank

Percentile

These can be calculated using : Table(across), Cell, or Specific dimensions!

When we create a reference line, we get the following 3 options for the scope:

Graphical user interface, chart Description automatically generated

A parameter is a global placeholder value such as a number, date, or string that can replace a constant value in a calculation, filter, or reference line.

For example, you may create a calculated field that returns True if Sales is greater than $500,000 and otherwise returns False. You can replace the constant value of “500000” in the formula with a parameter. Then, using the parameter control, you can dynamically change the threshold in your calculation.

For example -

The View Data window displays as much of the data as possible by default, up to 10,000 rows. This can be increased though, if you wish to.

Read more:

Explanation

Not too tough. Follow along the steps:

• Drag Color to Filter and choose Red:
• 3) Now to display the percentage correctly, lets format it. Click on the In Stock % pill in the Row shelf, and select format:
• And your final view will look like :

In Tableau, when you initially add a measure to the rows shelf, you create one mark in the view that represents the aggregate value of that measure. When you then add a dimension with 11 members to the columns shelf, the view is subdivided into 11 separate marks, each representing the measure for one of the dimension members. This results in a total of 11 marks in the view after the dimension is added, one for each member of the dimension.

To set the default properties of a field to Currency in Tableau, you need to configure the number format of the field from the Data pane. This can be done by right-clicking the field in the Data pane and selecting Default Properties, then choosing the appropriate number format (in this case, Currency).

Explanation

A geographic role associates each value in a field with a latitude and longitude value.

Assigning a geographic role based on the type of location (such as state versus postcode) helps ensure that your data is plotted correctly on your map view. For example, you can assign the City geographic role to a field that contains a list of city names.

To assign a geographic role to a field:

In the Data pane, click the data type icon next to the field, select Geographic Role, and then select the geographic role you want to assign to the field.

When you assign a geographic role to a field, Tableau adds two fields to the Measures area of the Data pane: Latitude (generated) and Longitude (generated).

These fields contain latitude and longitude values and are assigned the Latitude and Longitude geographic roles. If you double-click each of these fields, Tableau adds them to the Columns and Rows shelves and creates a map view using the Tableau background map.

When you use the 'Create Set' option in Tableau, it creates a dynamic set if the conditions for inclusion in the set are based on a calculation or an aggregation that may change as the data is updated or as filters are applied. Fixed sets are static and do not change with data refreshes, while dynamic sets can update to reflect the current state of the data.

Explanation

GDP / Population = GDP Per Capita

Here Sum is a function, / and + are operators. On the bottom there are comments.

A bullet graph is a variation of a bar graph developed to replace dashboard gauges and meters. A bullet graph is useful for comparing the performance of a primary measure to one or more other measures. Below is a single bullet graph showing how actual sales compared to estimated sales.

We can create a Bullet graph with just 2 measures! This method requires the LEAST number of fields possible to create this type of chart.

The best way to tackle such questions in the exam is to click the "SHOW ME" button on top right, and hover over the chart we want to create.

In our case, it is a Bullet graph.

Therefore, we need 2 measures at least to create this chart, and 0 or more dimensions.

According to the [Tableau Desktop Specialist Exam Guide], a join is a way to combine table columns in relational databases by using shared values. A join can be inner, left, right, or full, depending on how the matching rows are included or excluded.

Important question! If you selected Dimension and Measure, don't worry! It is a very common mistake. But we're here to learn aren't we?

When you connect to a new data source, Tableau assigns each field in the data source as dimension or measure in the Data pane, depending on the type of data the field contains. You use these fields to build views of your data.

According to the official Tableau documentation:

Before you can build a view and analyze your data, you must first connect Tableau to your data. Tableau supports connecting to a wide variety of data, stored in a variety of places.

By default, when you connect a data source to Tableau, Tableau will create a live connection to the data.

Live connection refers to a data source that contains direct connection to underlying data, which provides real-time or near real-time data. With a live connection, Tableau makes queries directly against the database or other source, and returns the results of the query for use in a workbook. Users can create live connections and then share them on Tableau Server so that other Tableau users can use the same data using the same connection and filtering settings.

Explanation

Yes, it is very much possible to use measures in the same view multiple times. For example, refer to the image below:

We are using BOTH the Sum of the revenue and the AVG of the revenue in the same view!

The following are the official definitions from the Tableau documentation for the various file types:

1) .tds (Tableau Data Source) - To not contain the actual data but rather the information necessary to connect to the actual data as well as any modifications you've made on top of the actual data such as changing default properties, creating calculated fields etc. (CORRECT ANSWER)

2) .twbx ( Tableau packaged workbook) - To create a single zip file that contains a workbook along with any supporting local file data and background images. This is great for sharing your work with others who don’t have access to the original data.

3) Extract (.hyper or .tde) – To create a local copy of a subset or entire data set that you can use to share data with others, when you need to work offline, and improve performance.

3) (.twb) Workbooks – To hold one or more worksheets, plus zero or more dashboards and stories.

According to the Tableau Desktop Specialist Exam Guide, a packaged workbook (.twbx) includes background images, extract files, and custom shapes. A PDF copy of the workbook and Tableau Datasource Customization (TDC) files are not included in a packaged workbook.

The only incorrect option is - It is mandatory to combine sheets when using Tableau.

All others are valid advantages that Dashboards provide when using Tableau!

It contains all the measures in your data, collected into a single field with continuous values - This is the definition for 'Measure Values'.

All others are True w.r.t. Measure Names!

The Measure Names field contains the names of all measures in your data, collected into a single field with discrete values.

Graphical user interface, text, application, email Description automatically generated

Documentation :

Since Sales is a measure, it can easily be depicted via size.

To drill down and change the level of detail, Country is the correct choice since it will contain STATE. We can then depict the various states by different shapes such as circle, square etc.

Finally, the Profit can be depicted via a color! Eg - Red for poor and green for excellent profits!

You can adjust the size for all charts except the Tree Map. You use dimensions to define the structure of the treemap, and measures to define the size or color of the individual rectangles. Treemaps are a relatively simple data visualization that can provide insight in a visually attractive format.

In a Tree Map, the measure itself defines the size and colour! The greater the sum of Measure for each category, the darker and larger its box.

The Marks Card allows us not only to edit the Shape, Text and Colour, but also to modify the Tooltip and the level of detail of the visualisation!

The Marks card is a key element for visual analysis in Tableau. As you drag fields to different properties in the Marks card, you add context and detail to the marks in the view.

You use the Marks card to set the mark type (see Change the Type of Mark in the View), and to encode your data with color, size, shape, text, and detail. To change the mark settings, see Control the Appearance of Marks in the View.

In this example, three different fields have been dragged to different properties in the Marks card. Segment is on Color, Region is on Shape, and Quantity is on Size.

After you add a field to the Marks card, you can click the icon next to the field to change the property it is using. You can also click the property buttons in the Marks card to change those settings.

Many properties can have multiple fields. For example, you can add multiple fields to Label, Detail, Tooltip, and Color. Size and Shape can only have one field at a time. For more details, see Control the Appearance of Marks in the View.

Explanation

Bin are a user-defined grouping of numerical data in the data source.

According to the official Tableau documentation: It's sometimes useful to convert a continuous measure (or a numeric dimension) into bins.

Have a look at the following image. When we right click a measure, we get the following options:

However, for a dimension (this is because the DATA TYPE of this dimension is a string:

But what if we have a dimension of type NUMBER (NUMERIC DIMENSION)? See below:

We can clearly create bins from dimensions too - they just have to be numeric :)

For more information, please refer to :

You can use Wildcard Search to set up search criteria to automatically include tables in your union. Use the wildcard character, which is an asterisk (*), to match a sequence or pattern of characters in the Excel workbook and worksheet names, Google Sheets workbook and worksheet names, text file names, JSON file names, .pdf file names, and database table names.

When working with Excel, text file data, JSON file, .pdf file data, you can also use this method to union files across folders, and worksheets across workbooks. Search is scoped to the selected connection. The connection and the tables available in a connection are shown on the left pane of the Data source page.

Explanation

When using a Blend, the primary data source appears with a BLUE tick-mark and the secondary data source appears with a ORANGE tick-mark.

See below:

The default behavior of Tableau when you add a measure to the view is to automatically apply an aggregation to that measure. The type of aggregation applied can vary depending on the context of the view. For example, if no other measures or dimensions affect the measure, Tableau might default to SUM. However, if there are other dimensions in the view that define the level of detail, the aggregation might be different to reflect the context.

According to the official Tableau documentation:

Tableau data source files have the .tds file extension. Data source files are shortcuts for quickly connecting to the original data that you use often. Data source files do not contain the actual data but rather the information necessary to connect to the actual data as well as any modifications you've made on top of the actual data such as changing default properties, creating calculated fields, adding groups, and so on. For more information, see Save Data Sources.

Explanation

Follow along the steps below:

• Drag Assortment and Year ID to the column shelf, and Item Number ID to the row shelf. Next, drag Sales to the Text label to create a cross-tab as below:

To combine data from another database with an existing data source in Tableau, the first step is to add a new connection. This will allow you to access the additional database and either blend or join the data from the two sources depending on your analysis needs.

From the official documentation, the following are the major advantages of using Tableau Data Extracts:

From Tableau 2020.2 onwards, .hyper is the recommended way since it is faster than .tde!

Data blending simulates a traditional left join. The main difference between the two is when the aggregation is performed. A join combines the data and then aggregates. A blend aggregates and then combines the data.

From the official website:

Explanation

TWBX is all in one. It contains viz, info needed to build the viz, and a copy of the data source. It doesn’t contain extracts of the data but can contain both live and data extracts. Best if want to eliminate the barrier of data access.

Create a .twbx with file-based data sources

1) Select File > Save As.

2) Specify a file name for the packaged workbook in the Save As dialog box.

3)Select Tableau Packaged Workbooks on the Save as type drop-down list.

4) Click Save.

5) The default location is the Workbooks folder of the Tableau repository. However, you can save packaged workbooks to any directory you choose.

The following files are included in packaged workbooks:

--> Background images

--> Custom geocoding

--> Custom shapes

--> Local cube files

--> Microsoft Access files

--> Microsoft Excel files

--> Tableau extract files (.hyper or .tde)

--> Text files (.csv, .txt, etc.)

Explanation

From the official Tableau website:

The Tableau workspace consists of menus, a toolbar, the Data pane, cards and shelves, and one or more sheets. Sheets can be worksheets, dashboards, or stories. For details on dashboard or story workspaces, see Create a Dashboard or The Story Workspace.

Graphical user interface, application Description automatically generated

The main thing you do in the workspace is to create visualisations to analyze your data.

Renaming data fields, cleaning the data, previewing the data can all be done in the Data source window.

We can use scatter plots to visualize relationships between numerical variables!

In Tableau, you create a scatter plot by placing at least one measure on the Columns shelf and at least one measure on the Rows shelf (Total 2 minimum). If these shelves contain both dimensions and measures, Tableau places the measures as the innermost fields, which means that measures are always to the right of any dimensions that you have also placed on these shelves. The word "innermost" in this case refers to the table structure.

 ( Simple Scatter Plot)

 (Matrix of Scatter Plots)

A scatter plot can use several mark types. By default, Tableau uses the shape mark type. Depending on your data, you might want to use another mark type, such as a circle or a square. For more information, see Change the Type of Mark in the View.

To create a scatter plot, follow the steps below:

Explanation

We can perform filter, URL and highlight actions out of the above given choices on a dashboard. Please refer to the image below:

Graphical user interface Description automatically generated

When creating a group by selecting headers in a Tableau view, the newly created grouped dimension replaces the original dimension field on either the Rows or Columns shelf. This grouping action aggregates the selected headers into a single group, and this new group dimension is automatically placed in the view, replacing the original dimension. This functionality allows for more simplified and customized categorization within the data visualization, enhancing the ability to analyze and interpret data according to specific groupings.

According to the official Tableau documentation:

Dimensions don't have aggregation properties, and adding properties manually each time defeats the whole DEFAULT aggregation purpose. Window tab doesn't have any default aggregation option!

For Standard Deviation and Variance, we don't need to use quick table calculations, since they are available by default. See below:

However, as seen in the types of quick table calculations available in Tableau, Rank and Moving Average belong to only this category.

After creating a dual axis chart, make sure to synchronise their axis since they both might not be having the same y-axis.

To align the two axes in a dual axes chart to use the same scale, right-click (control-click on Mac) the secondary axis, and select Synchronize Axis. This aligns the scale of the secondary axis to the scale of the primary axis.

In this example, the Sales axis is the secondary axis and the Profit axis is the primary axis.

If you would like to change which axis is the primary, and which axis is the secondary, select the field on the Columns or Rows shelf that is the secondary, and drag it in front of the primary field on the shelf until you see an orange triangle appear.

In this example, you can select the SUM(Sales) field on the Rows shelf, and drag it in front of the SUM(Profit) field. The Sales axis is now the primary and the Profit axis is the secondary.

Explanation

According to Tableau's official documentation -

Explanation

Data is generated and analyzed at many different levels of granularity. Granularity is the level of detail of the data. For example, when looking at graduation data, granularity would describe whether a row in the data set represents a single person or the graduating class of a university.

The option to create bins in Tableau is available for numeric fields. Bins allow you to group a series of numeric values into larger segments, which can simplify analysis and help in creating histograms or other visualizations that show the distribution of data. For example, you can create bins to group ages into categories like 0-10, 11-20, etc.

According to the official Tableau documentation:

Tableau packaged workbooks have the .twbx file extension. A packaged workbook is a single zip file that contains a workbook along with any supporting local file data and background images. This format is the best way to package your work for sharing with others who don’t have access to the original data. For more information, see Packaged Workbooks.

Explanation

According to the official Tableau documentation, there are 5 types of trend lines which we can work with in Tableau :

1) Linear Trend Line

2) Logarithmic Trend Line

3) Exponential Trend Line

4) Polynomial Trend Line

5) Power Model

Hence, the correct answer is BINOMIAL trend line which is not present in Tableau.

See the following image:

For more information, refer to:

You can change the device layout of a dashboard by using the Dashboard pane or the Dashboard menu. The Dashboard pane allows you to select a device type and customize the layout for that device. The Dashboard menu allows you to create a new device layout or copy an existing one. The Format menu and the Layout pane do not have options for changing the device layout1

Explanation

You can export the data in a Tableau data source, including all or part of the records from your original data. Alternatively, you can export only the portion of data used to generate the view.

Since the question mentions the data used to build the view, we'll focus on that :

*Export data in the view to Microsoft Access or .csv*

Export the data that is used to generate the view as an Access database (Windows only) or .csv file (Mac only).

1) In Tableau Desktop, select Worksheet > Export > Data.

2) Select a location and type a name for your Access database or .csv file.

3) Click Save.

4) If you're on Windows, the Export Data to Access dialog box displays to give you the option to immediately use the new Access database and continue working in Access without interrupting your work flow.

Graphical user interface, text, application, email Description automatically generated

To change a measure so that it automatically aggregates as an average instead of a sum, you should right-click the field in the Data pane and select Default Properties. In the Default Properties menu, you can set the default aggregation for the measure, such as setting it to calculate an average by default when added to a view.

According to the Tableau Help, there are two filter modes for continuous filters: Range of Values and Single Value. The help also states that “Range of Values lets you specify a minimum and maximum value for the filter using sliders or input fields” and “Single Value lets you select one value on a slider for the filter” (page 1).

Explanation

A Pareto chart is a type of chart that contains both bars and a line graph, where individual values are represented in descending order by bars, and the ascending cumulative total is represented by the line.

On the primary axis, bars are used to show the raw quantities for each dimension member, sorted in descending order.

On the secondary axis, a line graph is used to show the cumulative total in percent format.

Hierarchies in Tableau are used to define a drill-down path through your data. By creating a hierarchy, you can organize related fields together, which makes it easier to navigate complex data models. This also allows users to explore data at different levels of detail, from the highest level of the hierarchy to the most granular details, simply by clicking to expand and collapse levels of the hierarchy in the view.

When creating a date filter in Tableau, anchor refers to the date in a relative-date filter to which you anchor a unit of time. A relative-date filter is a type of filter that allows you to dynamically filter data based on a range of time relative to the current date or a specific date. For example, you can use a relative-date filter to show data for the last 7 days, the next 3 months, or the current quarter1 To create a relative-date filter, you need to specify the following options: The date field that you want to filter. The unit of time that you want to use for the filter, such as days, weeks, months, quarters, or years. The range of time that you want to show relative to the anchor date, such as last, next, this, or to date. The anchor date that you want to use as the reference point for the filter. You can use the current date or a custom date as the anchor date1 For example, if you want to create a relative-date filter that shows data for the last 3 months from January 1st, 2022, you would select the following options: Date field: Order Date Unit of time: Months Range of time: Last 3 Anchor date: Custom (01/01/2022) 1 The other options are not valid definitions of anchor when creating a date filter in Tableau. The mid-point in the range of displayed dates is not related to the anchor date, but rather to the center of the axis that represents the date field. The date in a range-of-dates filter to which you anchor units of time is not correct, because a range-of-dates filter does not use an anchor date, but rather a start and end date that can be fixed or dynamic. The latest date in the data source that can be found is not related to the anchor date, but rather to the maximum value of the date field in the data source2

Explanation

The INNER JOIN keyword selects all rows from both tables as long as there is a match between the columns. Consider 2 tables "Orders" and "Customers".

If there are records in the "Orders" table that do not have matches in "Customers", these orders will not be shown!

All answers except November are examples of Date Values (continuous in nature).

See below:

You can see that the option in Green symbolizes our correct answer, i.e only a Month. In our case that month is November (the correct answer).

All other options are combinations of a year with one other value (like a month, quarter, or day). So this is how by looking at an option you can know if its a date part or date value!

Explanation

For a manual sort, no matter how the data changes, the values will always stay in the sort order you kept stuff in.

From the official website:

Explanation

Pretty common question on the Tableau Desktop Specialist exam.

1) First, lets create Sheet 1. For this, drag sport to the Row shelf, and Weight to the Text mark in the Marks shelf. Change its aggregation to Average:

2) Now, for sheet 2 - Drag nationality to the view, and gold to the size mark in the Marks shelf.

NOTE: Depending on your version of Tableau , you may need to assign a Geographical role to the nationality column first as follows:

3) Now, let's create a dashboard, and use both these sheets in it:

4) Now, for the most Important step, use SHEET 2 AS A FILTER FOR SHEET 1 as follows:

Now simply click on Russia in Sheet 2, and Sheet 1 will automatically update as follows:

Explanation

Tableau recognises a CSV file as a TEXT file, and therefore it is the correct option.

The following are the steps to import a CSV file:

1) From the data connection screen, click on Text:

2) Choose the appropriate file, and click Open:

3) Finally, Tableau imports the data as shown below:

All of the given options are true except - Animations work well with maps, polygons, and density marks in web browsers.

From the official documentation:

As seen above, we can either turn the animations for the entire workbook (upper red box), or only for the current sheet ( lower red box )

1) Simultaneous animations

The default simultaneous animations are faster and work well when showing value changes in simpler charts and dashboards.

2) Sequential animations

Sequential animations take more time but make complex changes clearer by presenting them step-by-step.

This is one of the most common questions on the Tableau Desktop Specialist Exam.

Wrong options -

1) Don't use backgrounds - This is not a solution. What if we want to use backgrounds? We can't just stop using backgrounds to solve this problem.

2) Decrease the font size - Do you think using a smaller font will make the text more readable? No right? Hence, this is wrong too.

All other options are ways recommended to make your text more readable!

You can drag the filter by clicking on the 2 lines on top, and then dragging the filter as shown:

Explanation

It is possible in Tableau to use a sheet within a story directly.

Moreover, in Tableau, a story is a sequence of visualizations that work together to convey information. You can create stories to tell a data narrative, provide context, demonstrate how decisions relate to outcomes, or to simply make a compelling case.

At the same time, a story is also a collection of sheets, arranged in a sequence. Each individual sheet in a story is called a story point.

You can combine two sets to compare the members. When you combine sets you create a new set containing either the combination of all members, just the members that exist in both, or members that exist in one set but not the other.

Combining sets allows you to answer complex questions and compare cohorts of your data. For example, to determine the percentage of customers who purchased both last year and this year, you can combine two sets containing the customers from each year and return only the customers that exist in both sets.

To combine two sets, they must be based on the same dimensions. That is, you can combine a set containing the top customers with another set containing the customers that purchased last year. However, you cannot combine the top customers set with a top products set.

Text, letter Description automatically generated

Graphical user interface, text, application Description automatically generated

Graphical user interface, text, application, email Description automatically generated

According to the [Tableau Desktop Specialist Exam Guide], an incremental refresh only adds rows that are new, based on a specified column and value. A full refresh replaces all the extracted data with the data in the underlying data source. A full refresh is usually very slow, especially for large extracts. An incremental refresh can take less time, depending on how many new rows are added. A full refresh does not need to be configured, it is the default option for extracts in Tableau. An incremental refresh can be run from both Tableau Desktop and Tableau Server.

According to the Tableau Desktop Specialist Exam Readiness, a line chart will be created whenever you place measures on one shelf, and a date dimension on the other. This is because Tableau automatically recognizes date fields and treats them as continuous dimensions.

All are correct, except - Copy of any local file-based data. This is contained in a .tdsx file (Tableau Packaged Data Source)!

According to the official documentation -

According to the Tableau Help, headers are “labels that identify the different parts of your view”. The help also states that “Headers are created when you place a discrete dimension on Columns or Rows” (page 1).

The benefits of using a live connection over an extract include:

• B: A live connection ensures that the data in the workbook is as up-to-date as the database itself, providing fresher data compared to a static extract which is updated at intervals.
• C: A live connection queries the database server directly, which means it uses the server's memory and processing power rather than relying on the client computer's resources.

A live connection does not necessarily require less network overhead (A) as it may continually send queries over the network, and it is not always faster than an extract (D) because extracts can provide quicker response times for complex queries or large datasets.

Explanation

A bullet graph is a variation of a bar graph developed to replace dashboard gauges and meters. A bullet graph is useful for comparing the performance of a primary measure to one or more other measures.

Therefore, we need at least 2 measures for creating bullet graphs.

Only 1 option is correct -

Click on Dashboard in the Menu bar followed by Copy Image

Right click on the dashboard, and choose Copy, then image - Try doing this, you will end up copying just one of the worksheets not the entire dashboard

Click on Worksheet in the Menu bar followed by Export, then choose Image - Again, try doing this. You will end up copying just one of the worksheets not the entire dashboard

Using the floating export worksheet option on the Dashboard - No such option exists

No, by default, animations are not enabled in Tableau.

We can animate visualizations to better highlight changing patterns in your data, reveal spikes and outliers, and see how data points cluster and separate.

Animations visually transition between filter, sort, and zoom settings, different pages, and changes to filter, parameter, and set actions. As visualizations animate in response to these changes, viewers can more clearly see how data differs, helping them make better informed decisions.

When you author animations, you can choose between two different styles: simultaneous or sequential. Here are examples of each type.

1) Simultaneous animations

The default simultaneous animations are faster and work well when showing value changes in simpler charts and dashboards.

2) Sequential animations

Sequential animations take more time but make complex changes clearer by presenting them step-by-step.

To Animate visualizations in a workbook:

1) Choose Format > Animations.

2) If you want to animate every sheet, under Workbook Default, click On. Then do the following:

For Duration, choose a preset, or specify a custom duration of up to 10 seconds.

For Style, choose Simultaneous to play all animations at once or Sequential to fade out marks, move and sort them, and then fade them in.

3) To override workbook defaults for a particular sheet, change the settings under Selected Sheet.

According to the official Tableau documentation:

An example of an area chart is shown below:

Explanation

As the question mentions, we need to create a SET with the following conditions -> Choose only those customers whose Sales > 30,000

1) Right click on customer name --> Create --> Set

2) Let's Name the Set - Customer>30k ( you can name it anything you want :) )

Select USE ALL, and then move to the CONDITION TAB:

3) In the Condition Tab, Choose BY FIELD -> Select Sales -> Sum -> Greater than 30000 , and click OK

4) You should now have a new Set in the Data Pane as follows:

5) Drag this set to the rows shelf, and click on SHOW MEMBERS IN SET. Now drag Sales to the Column Shelf.

6) Click on the Show Mark Labels, and Sort ascending icons as shown:

7) Voila! We have our answer:

c

The relative date filter can be used to select a range of dates relative to the current date, such as the past month, the current quarter, etc. This filter type dynamically adjusts the range based on the current system date, making it suitable for use with the TODAY() function.

Explanation

Tableau displays data source connections and data fields for the workbook in the Data pane on the left side of the workspace.

The Data pane includes:

Dimension fields – Fields that contain qualitative values (such as names, dates, or geographical data). You can use dimensions to categorize, segment, and reveal the details in your data. Dimensions affect the level of detail in the view. Examples of dimensions include dates, customer names, and customer segments.

Measure fields – Fields that contain numeric, quantitative values can be measured. You can apply calculations to them and aggregate them. When you drag a measure into the view, Tableau applies an aggregation to that measure (by default). Examples of measures: sales, profit, number of employees, temperature, frequency.

For more information on what dimensions and measures are, see Dimensions and Measures, Blue and Green.

Calculated fields – If your underlying data doesn't include all of the fields you need to answer your questions, you can create new fields in Tableau using calculations and then save them as part of your data source. These fields are called calculated fields.

For more information on calculated fields, see Create Custom Fields with Calculations.

Sets – Subsets of data that you define. Sets are custom fields based on existing dimensions and criteria that you specify. For more information, see Create Sets.

Named sets from an MS Analysis Services server or from a Teradata OLAP connector also appear in Tableau in this area of the Data pane. You can interact with these named sets in the same way you interact with other custom sets in Tableau.

Parameters – Values that can be used as placeholders in formulas, or replace constant values in calculated fields and filters. For more information, see Create Parameters.

By default, the shape that a Heap map uses is a "Square". See below:

Dashboard actions in Tableau are interactive elements that can be used to create a more dynamic experience. These actions can be set to filter data on the dashboard, highlight specific elements, or even direct the user to a URL when interacting with a visualization. They can be triggered by user interaction such as hover, selection, or accessing a context menu. Moreover, dashboard actions can have multiple source sheets (where the action originates) and target sheets (where the action takes effect), allowing for a complex interactivity between different parts of the dashboard.
